Kapasitas Mesin

156.9 cc

Tipe Mesin

4 langkah, 4 katup, eSP+

Sistem Pendingin

Pendingin Cairan

Sistem Supply Bahan Bakar

PGM-FI (Programmed Fuel Injection)

Diameter x Langkah

60 x 55.5 mm

Rasio Kompresi

12:1

Daya Maksimum

11,3 kW (15,4 PS) / 8,500 rpm

Torsi Maksimum

13,8 Nm (1,5 kgf.m) / 7000 rpm

Transmisi

Otomatis, V-Matic

Sistem Starter

Elektrik

Sistem Transmisi

Otomatis, Sentrifugal, Tipe Kering

Tipe Minyak Pelumas

Basah

Tipe Rangka

Underbone - eSAF (enhanced Smart Architecture Frame)

Ukuran Ban Depan

110/90 - 12 M/C Tubeless

Ukuran Ban Belakang

130/80 - 12 M/C Tubeless

Rem Depan

220 mm Cakram Hidrolik (ABS) & 190 mm Cakram Hidrolik (CBS)

Rem Belakang

220 mm Cakram Hidrolik (ABS) & Tromol (CBS)

Sistem Pengereman

Anti-Lock Braking System (ABS) & Combi Brake System (CBS)

Tipe Suspensi Depan

Teleskopik

Panjang x Lebar x Tinggi

1.886 x 706 x 1.133 mm (ABS) & 1.886 x 701 x 1.133 mm (CBS)

Jarak Sumbu Roda

1.275 mm

Jarak Terendah ke Tanah

151 mm

Tinggi Tempat Duduk

768 mm

Sistem Pengapian

Full Transisterized

Tipe Baterai/Aki

MF 12V-5Ah

Tipe Busi

NGK LMAP8L-9
